Poynting 5G-XPOL-1-V2-41 Outdoor 4G LTE/5G 3dBi 4×4 MIMO Cross-Polarised Omni-Directional Antenna w/ SMA-Male Connector
Write a review below |
5/5
Call For Price
DISCOUNTED QUOTE
Want it by Tomorrow? Order before 4:00 PM for Next Business Day Delivery.
Availability
Out of stock
Condition New
Out of stock
Poynting 5G-XPOL-1-V2-41 Outdoor 4G LTE/5G 3dBi 4×4 MIMO Cross-Polarised Omni-Directional Antenna w/ SMA-Male Connector
Specifications
Antenna Specifications
Ports
- 4
SISO / MIMO
- 4×4 MIMO
Coax Cable Type
- HDF 195
Coax Cable Length
- 5m
Connector Type
- SMA (m)
Electrical Specifications
Frequency bands
- 698 – 960 MHz
- 1710 -2700 MHz
- 3400–3800 MHz
Gain (max)
- 3 dBi
VSWR
- < 2.5:1 – over 90% of the bands
Feed power handling
- 20 W
Input impedance
- 50 Ohm (nominal)
Polarisation
- Cross Polarised
Coax cable loss
- 0.362 dB/m @ 900 MHz
- 0.514 dB/m @ 1800 MHz
- 0.533 dB/m @ 2400 MHz
- 0.603dB/m @ 3000 MHz
DC short
- Yes, path to ground
Mechanical Specifications
Product dimensions
- 247 x 157 x 88 mm
Product weight
- 0.93 kg
Radome material
- UV Stable SAN Marine ASA
Radome colour
- Brilliant White Pantone P 179-1 C
Mounting Type
- Wall mount (included)
- Pole mount (included)
- Window mount (included)
Environmental Specifications, Certification & Approvals
Wind Survival
- < 250 km/h
- Note: Except for window mount configuration
Operating Temperature
- -40°C to 70°C
Environmental Conditions
- Outdoor/Indoor
Water ingress protection ratio/standard
- IP 65
Salt Spray
- MIL-STD 810G/ASTM B117
Operating Relative Humidity
- Up to 98%
Storage Humidity
- 5% to 95% – non-condensing
Storage Temperature
- -40°C to 70°C
Enclosure Flammability Rating
- UL 94-HB
Impact Resistance
- IK10
Product Safety & Environmental
- Complies with CE and RoHS Standards
