Cisco SWITCH CATALYST 3750V2-24PS (WS-C3750V2-24PS-S-4)

SKU: WS-C3750V2-24PS-S-4

Returns

14 day refund/replacements

Payments

Secure Transactions

Support

Live chat Support

Buy new:

Get Instant Price

Delivery Date:

Tomorrow, May 7

Order Within:

Loading timer...

Deliver to:

Secure Payment method

Returns

14 day refund/replacements

Payments

Secure Transactions

Support

Live chat Support

Not Sure How this Product will Suit You?

[product_pdf]

Cisco SWITCH CATALYST 3750V2-24PS (WS-C3750V2-24PS-S-4)

SKU: WS-C3750V2-24PS-S-4
Description

Cisco SWITCH CATALYST 3750V2-24PS (WS-C3750V2-24PS-S-4)

Cisco SWITCH CATALYST 3750V2-24PS

Specifications

Management features
Multicast support Yes
Switch type Managed
Quality of Service (QoS) support Yes
MIB support BRIDGE-MIB, CISCO-CDP-MIB, CISCO-CLUSTER-MIB, CISCO-CONFIG-MAN-MIB, CISCO-ENTITY-FRU-CONTROL-MIB, CISCO-ENVMON-MIB, CISCO-FLASH-MIB, CISCO-FTP-CLIENT-MIB, CISCO-HSRP-MIB, CISCO-HSRP-EXT-MIB, CISCO-IGMP-FILTER-MIB, CISCO-IMAGE-MIB, CISCO-IP-STAT-MIB, CISCO-L2L3-INTERFACE-CONFIG-MIB, CISCO-MAC-NOTIFICATION-MIB, CISCO-MEMORY-POOL-MIB, CISCO-PAGP-MIB, CISCO-PING-MIB, CISCO-PROCESS-MIB, CISCO-RTTMON-MIB, CISCO-STACK-MIB, CISCO-STACKMAKER-MIB, CISCO-STACKWISE-MIB, CISCO-STP-EXTENSIONS-MIB, CISCO-SYSLOG-MIB, CISCO-TCP-MIB, CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB, CISCO-VLAN-MEMBERSHIP-MIB, CISCO-VTP-MIB, ENTITY-MIB, ETHERLIKE-MIB, IF-MIB, IGMP-MIB, IPMROUTE-MIB, OLD-CISCO-CHASSIS-MIB, OLD-CISCO-FLASH-MIB, OLD-CISCO-INTERFACES-MIB, OLD-CISCO-IP-MIB, OLD-CISCO-SYS-MIB, OLD-CISCO-TCP-MIB, OLD-CISCO-TS-MIB, OSPF-MIB (RFC 1253), PIM-MIB, RFC1213-MIB, RFC1253-MIB, RMON-MIB, RMON2-MIB, SNMP-FRAMEWORK-MIB, SNMP-MPD-MIB, SNMP-NOTIFICATION-MIB, SNMP-TARGET-MIB, SNMPv2-MIB, TCP-MIB, UDP-MIB
Network
IGMP snooping Yes
Networking standards IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Full duplex Yes
Spanning tree protocol Yes
Rate limiting Yes
Number of VLANs 1000
Link aggregation Yes
IP routing Yes
Broadcast storm control Yes
Auto MDI/MDI-X Yes
Virtual LAN features
Number of VLANs 1000
Data transmission
Number of VLANs 1000
Supported data transfer rates 10/100/1000 Mbps
Jumbo frames support Yes
Maximum data transfer rate 1 Gbit/s
Sound emission
Acoustic pressure emissions 5.5 dB
Performance
Stackable Yes
Noise level 44 dB
Mean time between failures (MTBF) 261586 h
Flash memory 32 MB
Weight & dimensions
Weight (imperial) 4.54 kg (10 lbs)
Dimensions (W x D x H) (imperial) 443.5 x 295.1 x 43.9 mm (17.5 x 11.6 x 1.73″)
Weight 4.6 kg
Technical details
Stackable Yes
Noise level 44 dB
Mean time between failures (MTBF) 261586 h
Switch fabric speed 32 Gbps
Ports & interfaces
SFP module slots quantity 2
Basic switching RJ-45 Ethernet ports quantity 24
SFP/SFP+ slots quantity 2
Security
Static port security Yes
SSH/SSL support Yes
MAC address filtering Yes
IGMP snooping Yes
DHCP features DHCP server
Multicast features
Multicast support Yes
Protocols
Management protocols SNMP, SNMPv2, SNMPv3, RMON, Telnet, DNS
Certificates
Safety UL 60950-1, CUL to CAN/CSA 22.2 No. 60950-1, TUV/GS to EN 60950-1, CB to IEC 60950-1, NOM, CE Marking
Electromagnetic emissions FCC P 15 Class A, EN 55022 Class A (CISPR22), EN 55024 (CISPR24), AS/NZS CISPR22 Class A, CE, KCC, GOST
Memory
Flash memory 32 MB
Design
Safety UL 60950-1, CUL to CAN/CSA 22.2 No. 60950-1, TUV/GS to EN 60950-1, CB to IEC 60950-1, NOM, CE Marking
Stackable Yes
Power
Power consumption (typical) 444 W
Redundant power supply (RPS) support Yes
Input voltage 100 – 240 V
Input current 0.7 – 1.1 A
Power over Ethernet (PoE)
Power over Ethernet (PoE) Yes
Operational conditions
Storage temperature (T-T) -25 – 70 °C
Storage relative humidity (H-H) 10 – 85%
Operating temperature (T-T) 32 – 113 °F
Operating temperature (T-T) 0 – 45 °C
Operating relative humidity (H-H) 10 – 85%
Operating altitude 0 – 3000 m
Non-operating altitude 0 – 4573 m
Heat dissipation 1519 BTU/h
Other features
Dimensions (WxDxH) 443 x 295 x 44 mm
Connectivity technology Wired
Bandwidth 8 Gbit/s
Packet transfer speed 6.5 mpps
Networking features Ethernet, Fast Ethernet, Gigabit Ethernet
Input voltage 100 – 240 V
Input frequency 50/60 Hz
Connectivity LEDs Yes
Weight (imperial) 4.54 kg (10 lbs)
Switch fabric speed 32 Gbps
Electromagnetic emissions FCC P 15 Class A, EN 55022 Class A (CISPR22), EN 55024 (CISPR24), AS/NZS CISPR22 Class A, CE, KCC, GOST
Dimensions (W x D x H) (imperial) 443.5 x 295.1 x 43.9 mm (17.5 x 11.6 x 1.73″)
Acoustic pressure emissions 5.5 dB
