DrayTek Vigor 2136ax AX3000 Wireless Router with VPN and 2.5GbE WAN and LAN ports
Write a review below |
5/5
Excl. VAT: £134.50
Incl. VAT: £161.40
QTY DISCOUNT
Order before 4:00 PM for Same Day Dispatch.
Delivery
In Stock: Next Day
Condition New
In Stock: Next Day
DrayTek Vigor 2136ax AX3000 Wireless Router with VPN and 2.5GbE WAN and LAN ports
Specifications
| Ethernet LAN features | |
|---|---|
| Ethernet WAN | Yes |
| Ethernet LAN interface type | 2.5 Gigabit Ethernet |
| Ethernet LAN | Yes |
| Full duplex | Yes |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| DSL features | |
| DSL WAN | No |
| Mobile network | |
| SIM card slot | No |
| 3G/4G USB modem compatibility | Yes |
| Network | |
| Wake-on-LAN ready | Yes |
| Routing protocols | BGP, OSPF, RIP |
| Network address translation (NAT) | Yes |
| Guest access | Yes |
| Ethernet LAN interface type | 2.5 Gigabit Ethernet |
| Ethernet LAN | Yes |
| VPN tunnels quantity | 4 |
| VPN support | IPsec IKEv1, IKEv2, IKEv2 EAP, IPsec-XAuth, OpenVPN, WireGuard |
| Port forwarding | Yes |
| Networking standards | IEEE 802.1Q |
| Full duplex | Yes |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Port triggering | Yes |
| Wireless Distribution System (WDS) bridge | Yes |
| VPN server | yes |
| Static route | Yes |
| SSID-based VLAN assignment | Yes |
| Multicast support | Yes |
| Dynamic DNS (DDNS) | Yes |
| Port mirroring | Yes |
| VPN throughput | 390 Mbit/s |
| Management features | |
| Universal Plug and Play (UPnP) | Yes |
| WPS push button | Yes |
| Web-based management | Yes |
| Wake-on-LAN ready | Yes |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Bandwidth control | Yes |
| Intelligent Mesh technology | Yes |
| MU-MIMO technology | Yes |
| MIMO | Yes |
| Security | |
| VPN tunnels quantity | 4 |
| VPN support | IPsec IKEv1, IKEv2, IKEv2 EAP, IPsec-XAuth, OpenVPN, WireGuard |
| URL filtering | Yes |
| System event log | Yes |
| Security algorithms | 3DES, AES, HTTPS, SSH, SSID, TLS, WPA2, WPA2-PSK, WPA2-Personal, WPA2-RADIUS, WPA3, WPA3-Personal |
| Network address translation (NAT) | Yes |
| MAC address filtering | Yes |
| IP address filtering | Yes |
| Guest access | Yes |
| Firewall | Yes |
| DoS attack prevention | Yes |
| Schedule access | Yes |
| Parental control | Yes |
| Stateful Packet Inspection (SPI) | Yes |
| Access Control List (ACL) | Yes |
| DDoS protection | Yes |
| WAN connection | |
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | No |
| 3G/4G USB modem compatibility | Yes |
| WAN connection type | RJ-45 |
| Wireless LAN features | |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 3000 Mbit/s |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| WLAN data transfer rate (second band) | 2402 Mbit/s |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Ports & interfaces | |
| USB port | Yes |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 4 |
| DC-in jack | Yes |
| Protocols | |
| Universal Plug and Play (UPnP) | Yes |
| Routing protocols | BGP, OSPF, RIP |
| DHCP server | Yes |
| DHCP client | Yes |
| Design | |
| Product type | Desktop/pole router |
| Wall mountable | Yes |
| On/off switch | Yes |
| LED indicators | Activity, LAN, Power, USB, WLAN |
| Housing material | Plastic |
| Indication light | Yes |
| Certificates | |
| PSTI certified | Yes |
| Packaging content | |
| Cables included | LAN (RJ-45) |
| AC adapter included | Yes |
| Antenna included | Yes |
| Packaging content | •Vigor 2136ax series router •Quick Start Guide •Screws & wall plugs for wall mounting •2m Cat-5e RJ-45 Network Cable •2x Detachable Wireless LAN Antennas •DC 12V Power Supply with UK Plug |
| Antenna | |
| Antenna design | External |
| Detachable antenna(s) | Yes |
| Antenna gain level (max) | 2.7 dBi |
| Antenna connector type | RP-SMA |
| Antenna direction type | Omni-directional |
| Antenna type | 2×2 |
| Power | |
| Power over Ethernet (PoE) | No |
| Power consumption (typical) | 18 W |
| Operational conditions | |
| Storage temperature (T-T) | -25 – 70 °C |
| Operating temperature (T-T) | 0 – 45 °C |
| Operating relative humidity (H-H) | 10 – 90% |
| Weight & dimensions | |
| Width | 207 mm |
| Weight | 508 g |
| Height | 42 mm |
| Depth | 131 mm |
| Packaging data | |
| Cables included | LAN (RJ-45) |
| AC adapter included | Yes |
| Antenna included | Yes |
| Technical details | |
| PSTI certified | Yes |
